Set AHD video surveillance from the 1st camera and DVR CoVi Security HVK-1004 AHD PRO KIT

Specs CoVi Security HVK-1004 AHD PRO KIT

Type:

Set AHD video surveillance from the 1st camera and DVR

Camera

Model:

no data

Type of camera:

interior dome

The number of cameras, PCs:

1

The possibility of using on the street:

no

Resolution:

960p (1280x960)

Matrix:

A 1.3" color SONY

Focal length:

Varifocal 2,8-12 mm

Viewing angles horizontal/vertical:

27/82

Sensor type/CPU Type:

CMOS IMX238/no data

White balance:

auto

Infrared light:

up to 30m

Housing material:

plastic

Microphone/Speaker:

-/-

Operating temperature, °C / Humidity:

-20 to +50 / up to 95%

Size in mm:

no data

DVR

Model:

no data

Management: Linux

Video inputs:

4xBNC

Video outputs:

1xVGA, 1x HDMI

Audio inputs:

4xRCA

Audio outputs:

1xRCA, 1xHDMI

Standards video recording:

720p (1280x720), 960H (960х576)

The number of recording channels D1 real-time:

4

Supported drives: 4 TB, SATA

Alarm inputs:

no

Relay outputs:

no

USB 2.0:

2

Network interface:

RJ-45 (10/100M)

PTZ control:

RS485

Remote access from mobile devices:

no

Support CMS:

Yes

Cooler:

no

Operating temperature, °C / Humidity: range : -10 to +55 / 10% to 90%

Size in mm:

no data

Optionally

The functionality of the security system:

motion detection, the loss or absence of the video signal, close the camera

Recording modes: by : motion, alarm triggered, scheduled, manually

Package contents:

Software, DVR, power supply, remote control, USB mouse, camera (2 PCs) cable set (2 PCs ) to connect cameras, power divider 1/4

Other:

no
